SMC proportional valve
SMC proportional valve - ITV1050-312BL is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Description
Description
ITV1050-312BL
1、Stepless control of air pressure in proportion to electric signals
2、Sensitivity: 0.2 kPa (100 kPa specification)
3、Linearity: ±1% or less (F.S.)
4、Hysteresis: 0.5% or less (F.S.)
5、Communication: CC-Link, DeviceNetTM, PROFIBUS DP, RS-232C
ITVX2030-333BL
1、Stepless control of air pressure proportional to an electrical signal
2、Maximum supply pressure: 5.0 MPa
3、Set pressure range: 0.01 to 3.0 MPa
4、Maximum flow rate: 3000 L/min [ANR]
5、Fluid: Air, N2, O2, Ar
6、Wetted parts: Fluorine grease
